Clay Dryer
Clay dryer or clay drying machine is a specially designed dryer mainly used for drying clay, plaster and viscous materials.
E-mail:market@sinoftm.com Inquiry Us Now OnlineIntroduction
Clay dryer also can be called three return strokes dryer, mainly used for drying mortar, sand, cement, fly ash, coal gangue, slag, clay mixtures, gypsum, iron and other raw materials, widely used in building materials, chemical industry and foundry industry .Clay dryer or clay drying machine is a specially designed dryer mainly used for drying clay, plaster and viscous materials. Clay dryer uses advanced Germany drying technology, with reasonable structure, stable operation, simple operation, wear durability, higher thermal efficiency and better drying effect.
Features
Clay dryer uses the combination of high efficient lifting blade, which improves the exchange efficiency between the material and the hot air and accelerates the drying speed. Clay dryer is with large processing ability, high output, low investment, low operating and maintenance costs, energy saving and environmental protection, low production cost, etc.
Parameter
| Specification(mm) | Obliquity(%) | Speed(r/min) | Inlet Air Temperature(℃) | Power(KW) | Production Capacity(t/h) | Weight(t) |
| Φ600×6000 | 3-5 | 3-8 | ≤700 | 3 | 0.5-1.5 | 2.9 |
| Φ800×8000 | 3-5 | 3-8 | ≤700 | 4 | 0.8-2.0 | 3.5 |
| Φ800×10000 | 3-5 | 3-8 | ≤700 | 4 | 0.8-2.5 | 4.5 |
| Φ1000×10000 | 3-5 | 3-8 | ≤700 | 5.5 | 1.0-3.5 | 5.6 |
| Φ1200×10000 | 3-5 | 3-8 | ≤700 | 7.5 | 1.8-5 | 14.5 |
| Φ1200×12000 | 3-5 | 3-8 | ≤700 | 11 | 2-6 | 14.8 |
| Φ1500×12000 | 3-5 | 2-6 | ≤800 | 15 | 3.5-9 | 17.8 |
| Φ1800×12000 | 3-5 | 2-6 | ≤800 | 18 | 5-12 | 25 |
| Φ2200×12000 | 3-5 | 1.5-6 | ≤800 | 18.5 | 6-15 | 33 |
| Φ2200×18000 | 3-5 | 1.5-6 | ≤800 | 22 | 10-18 | 53.8 |
| Φ2200×20000 | 3-5 | 1.5-6 | ≤800 | 30 | 12-20 | 56 |
| Φ2400×20000 | 3-5 | 1.5-5 | ≤800 | 37 | 18-30 | 60 |
| Φ3000×20000 | 3-5 | 1.5-5 | ≤800 | 55 | 25-35 | 78 |
| Φ3000×25000 | 3-5 | 1.5-5 | ≤800 | 75 | 32-40 | 104.9 |
